Rockwell Automation PowerFlex 7000 Technical Data

2-226 Parameters Listed by Linear Number
7000-TD002A-EN-P – September 2007
Name Min. Max. Default Units
Read-
Only
Access
415 ExtFault14 Class - - Class2 Fault N Basic
416 ExtFault15 Class - - Class2 Fault N Basic
417 ExtFault16 Class - - Class2 Fault N Basic
418 Lmd 0.10 10.00 1.00 pu N Advanced
420 DvcDiag Flt Mask - - 1111111111111111 N Service
421 RunTime Input - - - Y Advanced
422 StndXIO Output - - - Y Advanced
423 Drv Wrn3 Mask - - 1111111111111111 N Basic
427 OptXIO Output - - - Y Advanced
428 Bypass VoltUnbal 0.00 1.00 - Y Service
429 External Warning - - - Y Service
431 StndXIO FltInput - - - Y Advanced
432 Pump Duty Cycle 1 720 8 hrs N Service
433 Stnd XIO Fault - - - Y Service
434 Stnd XIO Warning - - - Y Service
435 Stnd XIOFlt Mask - - 11111111 N Basic
439 StndXIO Config1 - - Reverse N Advanced
440 InputProt1 Class - - Class2 Fault N Basic
441 TxReacOvrTmpClss - - Class2 Fault N Basic
442 DCLnkOvrTmpClass - - Class2 Fault N Basic
443 Motor Prot Class - - Class2 Fault N Basic
444 InputProt2 Class - - Class2 Fault N Basic
445 Aux Prot Class - - Class2 Fault N Basic
446 InvControl Flag3 - - - Y Service
447 Convrter AirFlow -1.0 10.0 - V Y Basic
448 Stator Frequency 0.00 120.00 - Hz Y Service
449 Fan Duty Cycle 1 720 8 hrs N Service
458 StndXIO Config2 - - Jog N Advanced
459 StndXIO Config3 - - Remote N Advanced
460 StndXIO Config4 - - Test Mode N Advanced
461 StndXIO Config5 - - At Speed N Advanced
462 StndXIO Config6 - - Thermal Alrm N Advanced
463 StndXIO Config7 - - Sync Xfer N Advanced
464 StndXIO Config8 - - In Trq Limit N Advanced
465 Vdc Ref 7p to 5p 0.00 1.50 0.50 pu N Service
467 Drive Warning4 - - - Y Service
468 Drv Wrn4 Mask - - 1111111111111111 N Basic
472 Speed Error -10.00 10.00 - Hz Y Advanced
473 RecAnlg SelfTst1 - - - Y Service
474 RecAnlg SelfTst2 - - - Y Service
475 S Curve Percent 0 100 0 % N Advanced
477 Fan Config - - 3 In-line N Service
478 Coolant Temp Wrn 35 85 49 C N Service
479 S Curve Decel 1 0.0 1200.0 20.0 sec N Advanced
480 S Curve Decel 2 0.0 1200.0 20.0 sec N Advanced
481 S Curve Accel 1 0.0 1200.0 20.0 sec N Advanced
482 S Curve Accel 2 0.0 1200.0 20.0 sec N Advanced
483 Coolant Temp Trp 35 85 54 C N Service
485 StatFrqVoltModel 0.0 100.0 - Hz Y Service
486 StatFrqCurModel 0.0 100.0 - Hz Y Service
487 Motor Speed Hz -120.0 120.0 - Hz Y Basic
490 Fault Output 0 1 - Y Service
491 Fan1 Run Time 0.1 60.0 30.0 Days N Service
493 Fan2 Run Time 0.1 60.0 0.1 Days N Service
494 RecAnlg SelfTst3 - - - Y Service
500 Line Current 0 999 - A Y Basic
