Rockwell Automation PowerFlex 7000 Technical Data

Parameters Listed by Linear Number 2-227
7000-TD002A-EN-P – September 2007
Name Min. Max. Default Units
Read-
Only
Access
502 Feedforward Fil 0.0 12.0 2.0 Hz N Service
505 Contactor Cmd - - - Y Service
506 Contactor Status - - - Y Service
508 Anlg Output4 0 779 0 N Basic
509 Anlg RecTstPt1 0 779 321 N Service
510 Anlg RecTstPt2 0 779 322 N Service
511 Anlg InvTstPt1 0 779 490 N Service
512 Anlg InvTstPt2 0 779 289 N Service
513 Anlg Output1 0 779 0 N Basic
514 Anlg Output2 0 779 0 N Basic
515 Anlg Output3 0 779 0 N Basic
516 Anlg 4-20mAOut 0 779 337 N Basic
517 Anlg Meter1 0 779 361 N Basic
518 Anlg Meter2 0 779 362 N Basic
519 Anlg Meter3 0 779 363 N Basic
520 Anlg Meter4 0 779 364 N Basic
521 AnlgMeter1 Scale 0.00 655.35 1.00 N Basic
522 AnlgMeter2 Scale 0.00 655.35 1.00 N Basic
523 AnlgMeter3 Scale 0.00 655.35 1.00 N Basic
524 AnlgMeter4 Scale 0.00 655.35 1.00 N Basic
529 PLC Inp Link A1 0 779 0 N Basic
530 PLC Inp Link A2 0 779 0 N Basic
531 PLC Inp Link B1 0 779 0 N Basic
532 PLC Inp Link B2 0 779 0 N Basic
533 PLC Inp Link C1 0 779 0 N Basic
534 PLC Inp Link C2 0 779 0 N Basic
535 PLC Inp Link D1 0 779 0 N Basic
536 PLC Inp Link D2 0 779 0 N Basic
537 PLC Out Link A1 0 779 0 N Basic
538 PLC Out Link A2 0 779 0 N Basic
539 PLC Out Link B1 0 779 0 N Basic
540 PLC Out Link B2 0 779 0 N Basic
541 PLC Out Link C1 0 779 0 N Basic
542 PLC Out Link C2 0 779 0 N Basic
543 PLC Out Link D1 0 779 0 N Basic
544 PLC Out Link D2 0 779 0 N Basic
550 Motor Overload 0.00 1.00 - Y Service
551 Drive Overload 0.00 1.00 - Y Service
554 Motor Voltage pu 0.000 2.000 - pu Y Service
555 Motor Current pu 0.000 4.000 - pu Y Service
559 Field Loss Dly 0 60 30 sec N Service
560 Idc Fac 3p to 5p 0.00 2.00 1.00 N Service
561 Mtr Fault1 Mask - - 1111111111111111 N Basic
562 Drv Fault4 Mask - - 1111111111111111 N Basic
563 Drv Fault5 Mask - - 1111111111111111 N Basic
564 Ext Fault Mask - - 1111111111111111 N Basic
565 Mtr Wrn1 Mask - - 1111111111111111 N Basic
567 Air Filter Block 0.0 100.0 - % Y Basic
568 Air Filter Allow 0.0 100.0 - % Y Basic
569 DrvStatus Flag1 - - - Y Service
575 Number PwrSup 1 4 1 N Service
584 Inv DvcGat Seqn 0 65535 - Y Service
585 Mtr FluxUnbalTrp 0.00 1.00 0.05 pu N Advanced
586 Mtr FluxUnbalDly 0.0 10.0 1.0 sec N Advanced
587 LineNeutVoltTrp 0.00 1.50 0.40 pu N Advanced
588 LineNeutVoltDly 0.0 10.0 1.0 sec N Advanced
