Rockwell Automation PowerFlex 7000

3-56 Troubleshooting
7000-TD002A-EN-P – September 2007
WARNING
MESSAGE
WARNING
CODE
DESCRIPTION RECOMMENDED ACTIONS
2U1A Offline 286
2U1B Offline 292
2U1C Offline 298
2U4A Offline 289
2U4B Offline 295
2U4C Offline 301
2V3A Offline 288
2V3B Offline 294
2V3C Offline 300
2V6A Offline 291
2V6B Offline 297
2V6C Offline 303
2W2A Offline 287
2W2B Offline 293
2W2C Offline 299
2W5A Offline 290
2W5B Offline 296
2W5C Offline 302
PWM RECTIFIER SGCT WARNING
This warning occurs if Redn Dvc Rec option
is selected in HardwareOptions1 (P141).
This SGCT device on the rectifier side was
detected to be faulted after the input
contactor was closed or following a start
command or following a drive reset. After
isolating the drive from MV, ensure that the
device, IGDPS power supply and the fiber
optic signals are not damaged.
– Complete a resistance check per the
instructions in the manual
– NOTE: SGCTs may not have completely
shorted, and still could read in the kΩ
range – Any devices with low suspect
readings should be changed
– Check the LED status of the SCGT gate
driver card for abnormal readings
– Complete a Gating Test mode check on
the devices
– Verify the associated 20V power supply
is powered and active
– Verify all the power connections to the
SCGT firing card are seated properly
– NOTE: There is only the Redundant
option available on the Rectifier, and
only on 6P drives (SCR orPWM). You
can not have N-1 operation on the
rectifier since we can not control the line
voltage.
2U1A Online 268
2U1B Online 274
2U1C Online 280
2U4A Online 271
2U4B Online 277
2U4C Online 283
2V3A Online 270
2V3B Online 276
2V3C Online 282
2V6A Online 273
2V6B Online 279
2V6C Online 285
2W2A Online 269
2W2B Online 275
2W2C Online 281
2W5A Online 272
2W5B Online 278
2W5C Online 284
PWM RECTIFIER SGCT WARNING
This warning occurs if Redn Dvc Rec option
is selected in HardwareOptions1 (P141).
This SGCT device in the rectifier section
was detected to be faulted while the drive
was running. The drive detected that the
diagnostic feedback from this device did not
match the gating pattern. After isolating the
drive from MV, ensure that the device,
IGDPS power supply and the fiber optic
signals are not damaged.
– Complete a resistance check per the
instructions in the manual
– NOTE: SGCTs may not have completely
shorted, and still could read in the kΩ
range – Any devices with low suspect
readings should be changed
– Check the LED status of the SCGT gate
driver card for abnormal readings
– Complete a Gating Test mode check on
the devices
– Verify the associated 20V power supply
is powered and active
– Verify all the power connections to the
SCGT firing card are seated properly
– Reset the drive and let the offline
diagnostics further define the problem
– For nuisance faults, contact the factory
about extending the Diagnostic Delay
– NOTE: There is only the Redundant
option available on the Rectifier, and
only on 6P drives (SCR orPWM). You
can not have N-1 operation on the
rectifier since we can not control the line
voltage.
