Instrument
A3-16 ENVI-MAG Manual
SEP
The line or station separation.
The range is from 0 to 99999 with a decimal point, as
required, and can either be positive (+) or negative (-). It
may not necessarily represent the reading separation.
When the separation is positive, the station number
gets incremented by the separation.
When the separation is negative, the station number
gets decremented by the separation.
NOTE: a negative (W,S,-) station, when incremented,
becomes less negative, and vice versa.
LN
The line number, along which the measurements take
place.
It consists of the numeric part (
llll.l) and the
directional part [
d].
The range is from 0 to 99999 with a decimal point as
required.
The direction allows the entry of the geographical
direction or the Cartesian co-ordinates and is one of:
N,E,S,W, + or -.
Chg?:+_
ENTER
Depending upon which field the cursor is located in, you
will see one of these prompts.
Chg?:+- allows you toggle a selection from an
internal list by pressing either the “+” or “-” keys.
ENTER: Pressing “ENTER” will either pop-up a window
for further operation or let you enter a numeric value
(terminated by another press of the “ENTER” key)
help:INFO
This prompt indicates that the help screens are available
when you press the “INFO” key.
BATT
The voltage of the main battery. The normal range is
between 100 and approximately 140 when the charger
is connected.
The instrument may turn off without warning when the
value drops below 100 and will not allow more
measurements.
The data however still remains intact in memory, as long
as the main battery remains connected.
Parameter Description
