289
LOGO! Manual
A5E00380835-01
LOGO! DM8
12/24R
LOGO! 12/24RC
LOGO! 12/24RCo
Input current at
 Signal 0
Si l 1
< 1.0 mA (I1...I6)
< 0.05 mA (I7, I8)
1 A (I1 I6)
< 1.0 mA
 Signal 1 > 1.5 mA (I1... I6)
> 0.1 mA (I7, I8)
> 1.5 mA
Delay time at
 0 to 1 typ. 1.5 ms
<1.0 ms (I5, I6)
typ. 1.5 ms
 1 to 0
(, )
typ. 1.5 ms
<1.0 ms (I5, I6)
typ. 1.5 ms
Line length (unshielded) 100 m 100 m
Analog inputs
Number 2 (I7 = AI1, I8 = AI2)
Range 0 ... 10 V DC
input impedance
76 kW
Cycle time for analog value
generation
300 ms
max. Input voltage 28.8 V DC
Line length (shielded and
twisted)
10 m
Digital outputs
Number 4 4
Output type Relay outputs Relay outputs
Electrical isolation Yes Yes
In groups of 1 1
Control of a digital input Yes Yes
Output voltage
Output current
Technical data
