Siemens LOGO! - A.14 Technical data: LOGO!Power 12 V

LOGO! Manual
A5E00380835-01
290
LOGO! DM8
12/24R
LOGO! 12/24RC
LOGO! 12/24RCo
Continuous current I
th (per
terminal)
max. 10 A per relay max. 5 A per relay
Incandescent lamp load
(25000 switching cycles) at
1000 W 1000 W
Fluorescent tubes with ballast
(25000 switching cycles)
10 x 58 W 10 x 58 W
Fluorescent tubes, conven-
tionally compensated (25000
switching cycles)
1 x 58 W 1 x 58 W
Fluorescent tubes, uncom-
pensated (25000 switching
cycles)
10 x 58 W 10 x 58 W
Short circuit-proof and over-
load-proof
Short-circuit current limitation
Derating none; across the
entire temperature
range
none; across the
entire temperature
range
Short circuit-proof cos 1 Power protection
B16
600A
Power protection
B16
600A
Short-circuit proof cos 0.5 to
0.7
Power protection
B16
900A
Power protection
B16
900A
Parallel output circuits for
power increase
Not permitted Not permitted
Protection of output relay (if
desired)
max. 16 A,
characteristic B16
max. 16 A,
characteristic B16
Switching rate
Mechanical 10 Hz 10 Hz
Electrical
Ohmic load/lamp load 2 Hz 2 Hz
Inductive load 0.5 Hz 0.5 Hz
Technical data
