Detailed description
2.10 System settings for power-up, RESET/part-program end and part-program start
Basic logic functions: Mode group, channel, program operation, reset response (K1)
172 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Table 2-19 Effect of MD20112 $MC_START_MODE_MASK Bits 13 to 17
Bit 13 = 1 Bit 14 = 1 Bit 15 = 1 Bit 16 = 1 Bit 17 = 1
Guide value
coupling is
separated
reserved for
basic frame
reserved for
electronic gears
Initial setting for
master spindle
according to
MD20090
$MC_SPIND_DEF
_MASTER_SPIND
Only if MD20124
$MC_TOOL_MANAGEMENT_TOOLH
OLDER > 0: Initial setting for the
master tool holder according to MD
20124 $MC_Otherwise setting for
master spindle.
Bit 13 = 0 Bit 14 = 0 Bit 15 = 0 Bit 16 = 0 Bit 17 = 0
Active guide value
coupling is
retained
reserved for
basic frame
reserved for
electronic gears
current setting of
the master spindle
(SETMS) is
retained
The current setting of the
master tool holder (SETMS) is retained.
Note
In MD20110 $MC_RESET_MODE_MASK, bits set to 1 cause settings to be retained,
In MD20112 $MC_START_MODE_MASK, bits set to 0 cause settings to be retained.
Significance of the machine data
The channelspecific machine data in the table has the following significance. Details are
specified in section NO TAG.
• MD20120 $MC_TOOL_RESET_VALUE (Restart tool length compensation)
Definition of tool (T-No.),
whose tool length compensation values must be considered during RESET and power-up
according to MD20110 $MC_RESET_MODE_SCREEN
.
MD20121 $MC_TOOL_PRESEL_RESET_VALUE (Preselected tool on RESET)
Definition of tool (T-No.) as preselected tool, whose tool length compensation values
must be considered during RESET and power-up according to MD20110
$MC_RESET_MODE_SCREEN
.
MD20130 $MC_CUTTING_EDGE_RESET_VALUE (tool edge length compensation on
power-up)
Definition of the edge no. (D number) of the tool in
$MC_TOOL_RESET_VALUE
MD20140 $MC_TRAFO_RESET_VALUE (Power-up transformation data block)
Definition of transformation data block (TRAORI, TRAANG,
from SW 4 TRANSMIT)
MD20150 $MC_GCODE_RESET_VALUES (RESET position of G groups)
RESET positions of G groups
