5.2 SIMATIC RF210M
SIMATIC RF200
98 System Manual, 07/2015, J31069-D0227-U001-A9-7618
5.2.5
Display elements of the RF210M reader
Color
Meaning
green
flashing
Operating voltage present, reader not initialized or antenna switched off
permanently
lit
Operating voltage present, reader initialized and antenna switched on
yellow
1)
Transponder present
flashing red Error has occurred, the type of flashing corresponds to the error code in the
table in the section "Error
codes". The optical error display is only reset if the
corresponding reset parameter ("option_1 = 2") is set (see Product infor-
mation "SIMATIC RF200 command set"
(https://support.industry.siemens.com/cs/ww/en/view/44864850)).
1)
Only in the "with presence" mode.
5.2.6
Technical specifications of the RF210M reader
Table 5- 2 Technical specifications of the RF210M reader
6GT2823-0AA00
Product type designation
SIMATIC RF210M
Radio frequencies
Operating frequency, rated value
13.56 MHz
Electrical data
Maximum range
20 mm
Maximum data transmission rate reader ↔ tran-
sponder (tag)
ISO tags
• Read • approx. 1500 bytes/s
• Write • approx. 1500 bytes/s
Typical transmission time for user data per byte
• for write access • 0.6 ms
• for read access • 0.6 ms
Baud rate
19200, 57600, 115200 Bd
Read/write distances of the reader
see section "Field data (Page 37)"
Interfaces
Electrical connector design
M8, 8-pin
Standard for interfaces for communication
RS-422
Antenna
integrated
