Transponder
7.20 MDS D426
SIMATIC RF200
268 System Manual, 07/2015, J31069-D0227-U001-A9-7618
Design, dimensions and weight
Type of mounting 1 x M4 screw
2)
The values for shock and vibration are maximum values and must not be applied continuously.
2
) To prevent it loosening during operation, secure the screw with screw locking varnish.
Figure 7-51 Dimension drawing of MDS D426
