Transponder
7.3 MDS D117
SIMATIC RF200
System Manual, 07/2015, J31069-D0227-U001-A9-7618
195
6GT2600-0AG00
Design, dimensions and weight
Dimensions (Ø x H)
4 x 5.2 mm
Weight
1 g
Type of mounting
• Fixing pocket
• Glued
1)
The values for shock and vibration are maximum values and must not be applied continuously.
7.3.5
Dimension drawing
Figure 7-5 Dimensions in mm
