Siemens SIMATIC Ident System Manual

Appendix
A.2 Accessories
SIMATIC RF200
324 System Manual, 07/2015, J31069-D0227-U001-A9-7618
A.2.3.6
Technical specifications
General technical specifications
Insulation stability (prim./sec.) U
ins p/s
3.3 kV
AC
Insulation resistance R
ins
>1 GΩ
Leakage current I
leak
U
in
= 230 V
AC
, f = 50 Hz
< 200 µA
Safety class (SELV)
Designed for installation in devices of Safety Class 2
Mains buffering t
h
U
in
= 230 V
AC
≥ 50 ms
Ambient temperature
-25 ℃ ... +55 ℃
Surface temperature
Module top, center
max. 96 ℃
Storage temperature
-40 ℃ ... +85 ℃
Self-heating on full-load
max. 45 K
Interference immunity
ESD
HF fields
Burst
Surge
HF injection
Mains quality test
EN 61000-4-2,
4-3 to 4-6, 4-11 Air discharge: 15 kV
10 V/m
symmetrical: 2
symmetrical: 1
10 V
rms
Cooling
Free convection
Dimensions L x W x H
175 mm x 85 mm x 35 mm
Weight
720 g
Housing / casting
UL 94-V0
Power supply class according to CSA Level 3
Degree of protection IP65
MTBF in years 255
Technical specifications - input
Rated input voltage U
in
EN 60950 / UL 60950 100 to 240 VAC
120 to 353 VDC
Input frequency f
in
50/60 Hz
Radio interference level
EN 55011/B
Switching frequency f
sw
approx. 70 kHz typ.
Length of cable
2 m
Technical specifications - output
Output voltage tolerance ∆U
out
U
in
= 230 V
AC
U
out nom
≤ +2 %/-1 %
Overvoltage protection
U
out nom
+20 % typ.
Noise ∆U
LF
U
in
= min., BW: 1 MHz
≤ 1 % U
out
Noise ∆U
HF
U
in
= min., BW: 20 MHz
≤ 2 % U
out
