Transponder
7.23 MDS D521
SIMATIC RF200
276 System Manual, 07/2015, J31069-D0227-U001-A9-7618
Area of application The MDS D521 is designed for tool coding according to DIN
69873.
It can be used wherever small data carriers and exact positioning
are required, e.g. tool identification, workpiece holders.
The rugged housing of the MDS D521 means that it can also be
used in a harsh industrial environment without problems.
8192 bytes of FRAM user memory
See section "Field data (Page 37)"
Yes, flush-mounted in metal
Table 7- 57 Ordering data for MDS D521
Mounting on metal
Mounting on metal
Figure 7-57 Mounting of MDS D521 on metal
