Page #180 background imageLoading...
Page #180 background image
Antennas
6.8 ANT D10
SIMATIC RF200
180 System Manual, 07/2015, J31069-D0227-U001-A9-7618
6.8
ANT D10
6.8.1
Features
ANT D10
Characteristics
Area of application
• Storage, logistics and distribution, e.g. clothing industry,
laundries
• Particularly when small MDS are used (e.g. MDS D124,
MDS D160) and when there is a long transmission field
Writing/reading distance
up to 480 mm (depending on the transponder)
Connecting cable
3.3 m; included in scope of supply
Cover Included in scope of supply
Readers that can be connected
RF290R
6.8.2
Ordering data
Table 6- 14 Ordering data of ANT D10
Antenna
Article number
ANT D10
(incl. cover and one antenna connecting cable 3.3 m)
6GT2698-5AF00
Table 6- 15 Ordering data of ANT D10 accessories
Accessories
Article number
Antenna splitter
(incl. one antenna connecting cable 3.3 m)
6GT2690-0AC00
Antenna multiplexer
(incl. one antenna connecting cable 0.4 m)
6GT2894-0EA00
Antenna cable
Length 3.3 m
6GT2691-0CH33
Length 10.5 m
6GT2691-0CN10
Antenna extension cable, length 7.2 m
6GT2691-0DH72
