Siemens SIMATIC Ident System Manual

Antennas
6.8 ANT D10
SIMATIC RF200
184 System Manual, 07/2015, J31069-D0227-U001-A9-7618
6.8.6
Technical data
6GT2698-5AF00
Product type designation
ANT D10
Electrical data
Maximum write/read distance ANT ↔ transponder
(S
g
)
480 mm
Interfaces
Plug connection
1-pin TNC plug
Mechanical specifications
Housing
• Material • Aluminum/plastic
• Color • gray/black
Permitted ambient conditions
Ambient temperature
• During operation • -20 °C ... +55 °C
• During transportation and storage • -25 ℃ ... +70 ℃
Degree of protection to EN 60529
IP65 (UL: for indoor use only)
Shock-resistant to EN 60721-3-7, Class 7 M3
30 g
1)
Vibration-resistant to EN 60721-3-7, Class 7 M3
• 1 g (9 ... 200 Hz) /
1)
• 1.5 g (200 ... 500 Hz)
1)
Design, dimensions and weights
Dimensions (L x W x H) 1150 x 365 x 115 mm
(with cover)
Weight 10 kg
Type of mounting 2 x M6 screws
Cable length 3.3 m
1)
Warning: The values for shock and vibration are maximum values and must not be applied contin-
uously.
