Siemens SIMATIC Ident System Manual

Antennas
6.1 ANT 3
SIMATIC RF200
146 System Manual, 07/2015, J31069-D0227-U001-A9-7618
6.1.6
Technical data
6GT2398-1CD30-0AX0
6GT2398-1CD40-0AX0
Product type designation
ANT 3
Electrical data
Maximum write/read distance
ANT ↔ Transponder (S
g
)
50 mm
Interfaces
Plug connection M8, 4-pin socket on antenna side (with antenna
connecting cable: pin cable end)
Mechanical specifications
Housing
• Material • Plastic PA6-V0
• Color • Black
MTBF
1.2 × 10
8
h
Permitted ambient conditions
Ambient temperature
• During operation • -25 °C ... +70 °C
• During transportation and storage • -40 °C ... +85 °C
Degree of protection to EN 60529
IP67
Shock-resistant to EN 60721-3-7, Class 7 M3
50 g
1)
Vibration-resistant to EN 60721-3-7, Class 7 M3
20 g
1)
Design, dimensions and weight
Dimensions (L × W × H)
• Housing without antenna connector • 50 × 28 × 10 mm
• Housing with antenna connector • 240 × 28 × 10 mm
Weight
• Housing with antenna connector • Approx. 35 g
• Housing with antenna connector and antenna
cable
• Approx. 160 g
Type of mounting
2 x M4 screws
Cable length
3 m (plug-in antenna cable)
1)
Warning: The values for shock and vibration are maximum values and must not be applied contin-
uously.
