Siemens SIMATIC Ident System Manual

Transponder
7.15 MDS D421
SIMATIC RF200
System Manual, 07/2015, J31069-D0227-U001-A9-7618
249
Installation examples
Figure 7-37 Installation example of MDS D421 in a steep cone
Figure 7-38 Installation example of MDS D421 in a stud bolt
7.15.4
Technical specifications
Table 7- 38 Technical specifications for the MDS D421
6GT2600-4AE00
Product type designation
SIMATIC MDS D421
Memory
Memory configuration
• UID • 8 bytes
• User memory • 2000 bytes FRAM
• OPT memory • 16 bytes FRAM
Read cycles (at < 40 ℃)
> 10
12
Write cycles (at < 40 ℃)
> 10
12
Data retention time (at < 40 ℃)
> 10 years
Write/read distance (S
g
) Dependent on the reader used, see section "Field
data (Page 37)"
MTBF (Mean Time Between Failures)
2 x 10
6
hours
Mechanical specifications
Housing
• Material • Epoxy resin
• Color • Black
