Transponder
7.15 MDS D421
SIMATIC RF200
250 System Manual, 07/2015, J31069-D0227-U001-A9-7618
Recommended distance to metal
Inductive, without battery
Permitted ambient conditions
• During operation • -25 to +85 ℃
• During transportation and storage • -40 to +100 ℃
Degree of protection to EN 60529
• IP67
• IPx9K
steam jet: 150 mm; 10 to 15 l/min; 100 bar; 75
°C
Shock-resistant to EN 60721-3-7 class 7M3
1)
Vibration-resistant to EN 60721-3-7, class 7M3
1)
Design, dimensions and weight
2)
The values for shock and vibration are maximum values and must not be applied continuously.
2)
The manufacturer's processing instructions must be observed.
Figure 7-39 Dimension drawing of MDS D421
