Siemens SIMATIC Ident System Manual

RF200 system planning
4.3 Installation guidelines
SIMATIC RF200
56 System Manual, 07/2015, J31069-D0227-U001-A9-7618
Transponder
Reader without direct
metal influence
(Case a, b and d)
Reader flush-
mounted in metal
(Case c)
MDS D522
metal-free
100
90
flush-mounted in metal;
distance all round 0 mm
85 85
MDS D522
Special variant
metal-free
100
90
flush-mounted in metal;
distance all round 0 mm
85 85
MDS D524
1)
metal-free
100
93
on metal, distance 0 mm
96
89
flush-mounted in metal;
distance all round 0 mm
86 82
MDS D526
1)
metal-free
100
90
on metal, distance 25 mm
90
75
flush-mounted in metal;
distance all round 50 mm
80 70
MDS D528
metal-free
100
94
on metal, distance 0 mm
100
94
1)
Mounting the transponder on or in metal is only possible with the appropriate spacer or if there is
adequate clearance to the metal.
2)
Values of > 100 % related to non metal surroundings can occur if transponders were developed
specifically for mounting in/on metallic surroundings.
4.3.4.3
RF240R
The RF240R can be flush-mounted in metal. Please allow for a possible reduction in the field
data values.
Figure 4-11 metal-free space RF240R
