Siemens SIMATIC Ident System Manual

System diagnostics
9.2 Diagnostic functions
SIMATIC RF200
306 System Manual, 07/2015, J31069-D0227-U001-A9-7618
Note
Error message when memory area is protected
For transponders with a locked or protected memory area, different error messages can
occur following a write command depending on the data carrier type, e.g. MDS
D1xx (NXP),
D3xx (Infineon), D4xx (Fujitsu): Error 01, 0C
9.2
Diagnostic functions
Further information on RFID diagnostics options can be found in the following function
manuals:
● Function Manual FB 45 (https://support.industry.siemens.com/cs/ww/en/view/21738808
)
● Function manual Ident profile and Ident blocks
(https://support.industry.siemens.com/cs/us/en/view/106368029
)
Diagnostics with FB 45 is described below.
9.2.1
Reader diagnostics with SLG STATUS
The SLG STATUS command can be used to scan the status and diagnostics data of the
reader.
SLG STATUS (mode 01), corresponds to UDT 110
Name
Type
Possible values
Comment
hardware char (31 to 38 hex)
31 hex
32 hex
33 hex
34 hex
3A hex
Type of hardware
= RF260R
= RF210/220R
= RF240R
= RF250R
= RF290R
hardware_version word
0 to FF hex
0 to FF hex
HW version (reserved)
= Version (high byte)
= Version (low byte)
loader_version word
0 to FF hex
0 to FF hex
Bootstrap loader version: e.g. 3130 (=version
1.0)
= Version (high byte)
= Version (low byte)
firmware
char
0 to FF hex
FW version : 33 (ASCII : 3 = RF2x0R)
firmware_version word
0 to FF hex
0 to FF hex
Firmware version: e.g. 3130 (=version 1.0)
= Version (high byte)
= Version (low byte)
