Siemens SIMATIC Ident System Manual

Readers
5.6 SIMATIC RF260R
SIMATIC RF200
124 System Manual, 07/2015, J31069-D0227-U001-A9-7618
5.6.6
Technical data of the RF260R reader
Table 5- 6 Technical specifications of the RF260R reader
6GT2821-6AC10
6GT2821-6AC11
6GT2821-6AC40
Product type designation
SIMATIC RF260R
Radio frequencies
Operating frequency, rated value
13.56 MHz
Electrical data
Maximum range
135 mm
Maximum data transmission rate reader ↔ tran-
sponder (tag)
ISO tags
• Read • approx. 1500 bytes/s
• Write • approx. 1500 bytes/s
Typical transmission time for user data per byte
• for write access • 0.6 ms
• for read access • 0.6 ms
Baud rate
19200, 57600, 115200 Bd
Read/write distances of the reader
see section "Field data (Page 37)"
Interfaces
Electrical connector design
M12, 8-pin
Standard for interfaces for communication
• 6GT2821-6AC10 • RS-422 (3964R protocol)
• 6GT2821-6AC11 • RS-232 (3964R protocol)
• 6GT2821-6AC40 • RS-232 (ASCII protocol)
Antenna
integrated
Mechanical specifications
Housing
• Material • Plastic PA 6.6
• Color • Anthracite
Recommended distance to metal 0 mm
