Page #93 background imageLoading...
Page #93 background image
Readers
5.1 SIMATIC RF210R
SIMATIC RF200
System Manual, 07/2015, J31069-D0227-U001-A9-7618
93
5.1.6
Technical specifications of the RF210R reader
Table 5- 1 Technical specifications of the RF210R reader
6GT2821-1AC10
Product type designation
SIMATIC RF210R
Radio frequencies
Operating frequency, rated value
13.56 MHz
Electrical data
Maximum range
20 mm
Maximum data transmission rate reader ↔ tran-
sponder (tag)
ISO tags
• Read • approx. 1500 bytes/s
• Write • approx. 1500 bytes/s
Typical transmission time for user data per byte
• for write access • 0.6 ms
• for read access • 0.6 ms
Baud rate
19200, 57600, 115200 Bd
Read/write distances of the reader
see section "Field data (Page 37)"
Interfaces
Electrical connector design
M8, 8-pin
Standard for interfaces for communication
RS-422
Antenna
integrated
Mechanical specifications
Housing
• Material • Brass, nickel-plated
• Color • Silver
Recommended distance to metal 0 mm
Supply voltage, current consumption, power loss
Supply voltage
24 VDC
Typical current consumption 50 mA
