5.7 SIMATIC RF290R
SIMATIC RF200
136 System Manual, 07/2015, J31069-D0227-U001-A9-7618
5.7.6
Technical specifications of the RF290R reader
Table 5- 11 Technical specifications of the RF290R reader
6GT2821-0AC12
Product type designation
SIMATIC RF290R
Radio frequencies
Operating frequency, rated value
13.56 MHz
Electrical data
Maximum range
65 mm
Maximum data transmission rate reader ↔ tran-
sponder (tag)
ISO tags
• Read • approx. 1500 bytes/s
• Write • approx. 1500 bytes/s
Typical transmission time for user data per byte
• for write access • 0.6 ms
• for read access • 0.6 ms
Multitag capability
When connected via a PC
Baud rate
19200, 57600, 115200 Bd
Read/write distances of reader
see section "Field data (Page 37)"
Interfaces
Electrical connector design
TNC
Standard for interfaces for communication
• RS-422
• RS-232
Antenna
external, ANT D5, D6 or D10 can be connected
Mechanical specifications
Housing
• Material • Aluminum die-casting
• Color • Silver/anthracite
Recommended distance to metal
0 mm
Supply voltage, current consumption, power loss
Supply voltage
24 VDC (± 10%)
Typical current consumption
400 mA (at 24 V and 5 W)
