Antennas
6.1 ANT 3
SIMATIC RF200
144 System Manual, 07/2015, J31069-D0227-U001-A9-7618
6.1.4
Operating / limit distances
The operating / limit distances listed in the following table relate to an ANT 3 mounted on
metal.
Table 6- 3 Operating / limit distances of the transponders
RF250R with ANT 3
Operating distance (S
a
)
RF250R with ANT 3
Limit distance (S
g
)
MDS D124
2 ... 32
40
MDS D160
1 ... 16 20
MDS D324
2 ... 32
40
MDS D422
1 ... 12
15
MDS D423
(without metal)
0 ... 20 25
MDS D423
(on metal)
0 ... 24 30
MDS D423
(in metal - 10 mm clear-
ance all round)
0 ... 24 30
MDS D423
(in metal - 0 mm clear-
ance all round)
0 ... 16 20
MDS D424
0 ... 45
50
MDS D425
0 ... 16
20
MDS D428
0 ... 25
32
MDS D460
0 ... 18
25
MDS D522
1 ... 12
15
MDS D522
Special variant
1 ... 12 15
MDS D524
1 ... 30
40
MDS D528
1 ... 20
25
All values are in mm
6.1.5
Minimum spacing
Note
Extension of the data transmission time if distance values are undershot
If the distance values specified in the
tables are undershot, it is possible that the inductive
fields will be affected. In this case, the data transmission time can increase unpredictably or
a command is aborted with an error.
For this reason, please observe the values in the tables.
