Siemens SIMATIC Ident System Manual

Antennas
6.6 ANT D5
SIMATIC RF200
System Manual, 07/2015, J31069-D0227-U001-A9-7618
169
6.6
ANT D5
6.6.1
Features
ANT D5
Characteristics
Area of application
Storage, logistics and distribution
Writing/reading distance up to 500 mm (depending on the transponder)
Connecting cable
3.3 m
Readers that can be con-
nected
RF290R
Degree of protection IP65
6.6.2
Ordering data
Table 6- 10 Ordering data of ANT D5
Antenna
Article number
ANT D5
(incl. one antenna connecting cable 3.3 m)
6GT2698-5AA10
Table 6- 11 Ordering data of ANT D5 accessories
Accessories
Article number
Antenna splitter
(incl. one antenna connecting cable 3.3 m)
6GT2690-0AC00
Antenna multiplexer
(incl. one antenna connecting cable 0.4 m)
6GT2894-0EA00
Antenna cable
Length 3.3 m
6GT2691-0CH33
Length 10.5 m
6GT2691-0CN10
Antenna extension cable, length 7.2 m
6GT2691-0DH72
