Transponder
7.24 MDS D522
SIMATIC RF200
282 System Manual, 07/2015, J31069-D0227-U001-A9-7618
Mounting information for screws
You can screw the transponder into a pre-drilled threaded hole using the screw-in aid.
Mounting information for adhesion
● Drill installation hole
● The adhesive surfaces must be dry, free from dust, oil, stripping agents and other
impurities
● Apply adhesive according to the manufacturer's processing instructions
● Press in MDS D522 using your fingers; with antenna to the outside
● Remove residues of adhesive
● Allow to cure according to the manufacturer's instructions
● Flush-mounting of MDS D522 in metal with tools
7.24.4
Technical specifications
Table 7- 60 Technical specifications for MDS D522
6GT2600-5AF00
Product type designation
SIMATIC MDS D522
Memory
Memory configuration
• UID • 8 bytes
• User memory • 8192 bytes FRAM
Read cycles (at < 40 ℃)
> 10
12
Write cycles (at < 40 ℃)
> 10
12
Data retention time (at < 40 ℃)
> 10 years
Write/read distance (S
g
) Dependent on the reader used, see section "Field
data (Page 37)"
MTBF (Mean Time Between Failures)
2.5 x 10
6
hours
Mechanical specifications
Housing
• Material • Plastic PA 6.6 GF; brass nickel plated
• Color • Black/silver
Recommended distance to metal
> 0 mm
Power supply
Inductive, without battery
