Siemens SIMATIC Ident System Manual

System diagnostics
9.2 Diagnostic functions
SIMATIC RF200
System Manual, 07/2015, J31069-D0227-U001-A9-7618
307
Name
Type
Possible values
Comment
driver char
31 hex
Type of driver
3964R
driver_version word
0 to FF hex
0 to FF hex
Driver version: e.g. 3132 (=version 1.2)
= Version (high byte)
= Version (low byte)
interface byte
01 hex
02 hex
Interface type
= RS-422
= RS-232
baud byte
01 hex
03 hex
05 hex
Baud rate
= 19.2 kBd
= 57.6 kBd
= 115.2 kBd
multitag_SLG byte
01 hex
Number of transponders (multitag/bulk) that can
be processed in the antenna field
= Single tag mode
field_ON_time_SLG byte 01 hex ISO transponder (non-specific)
status_ant byte
01 hex
02 hex
Status of antenna
= Antenna is on
= antenna is off
MDS_control byte
00 hex
01 hex
Presence status
= Operation without presence message
= Operation with presence message
Note
Unassigned fields in the UDT are not listed here.
