Siemens SIMATIC Ident System Manual

RF200 system planning
4.3 Installation guidelines
SIMATIC RF200
System Manual, 07/2015, J31069-D0227-U001-A9-7618
55
To avoid any influence on the field data, in Case d, the distance a should be ≥ 15 mm.
Table 4- 17 Reduction of field data due to metal, range as %: Transponder and RF220R
Transponder
Reader without direct
metal influence
(Case a, b and d)
Reader flush-
mounted in metal
(Case c)
MDS D124
1)
metal-free
100
94
on metal, distance 15 mm 97 89
tag flush-mounted in metal;
distance all round 15 mm
86 83
MDS D126
1)
metal-free 100 75
on metal, distance 25 mm
85
70
flush-mounted in metal;
distance all round 50 mm
80 65
MDS D160
1)
metal-free
100
89
on metal, distance 10 mm
100
89
MDS D324
1)
metal-free
100
90
on metal, distance 15 mm
97
86
flush-mounted in metal;
distance all round 25 mm
93 86
MDS D422
metal-free
100
90
flush-mounted in metal;
distance all round 0 mm
85 85
MDS D423
metal-free
100
90
on metal, distance 0 mm
125
2)
115
2)
flush-mounted in metal;
distance all round 10 mm
80 75
MDS D424
1)
metal-free 100 93
on metal, distance 15 mm
96
89
flush-mounted in metal;
distance all round 25 mm
86 82
MDS D425
metal-free
100
90
screwed onto metal 100 75
flush-mounted in metal;
distance all round 25 mm
95 75
MDS D426
1)
metal-free
100
90
on metal, distance 25 mm
90
75
flush-mounted in metal;
distance all round 50 mm
80 70
MDS D428
metal-free
100
94
on metal, distance 0 mm
100
94
MDS D460
1)
metal-free
100
92
on metal, distance 0 mm
100
92
