Technical specifications - output
Regulation
• Line regulation
• Load regulation
• U
in
= min./max.
• I
out
= 10...90...10 %
• ≤ 1,0 %
• ≤ 1,0 %
Short-circuit current I
max
I
nom
= 4 A (+50 °C)
105 ... 130 % I
nom
Settling time t
R
load variations
I
out
= 10 ... 90 ... 10 %
< 5 ms
Temperature coefficient ε
T
A
= -25 °C to +70 °C
0.01 %/K
Overload behavior P
over
Constant current
Short-circuit protection/
No-load response
Continuous/no-load stability
Derating
T
A
> +50 °C to +70 °C
max. 2 %/K
Connector type M12, 4-pin;
two sockets
Technical specifications - initial configurations
Input
Outputs U1 = U2
ILoad = I1 + I2
Efficiency (%)
Remarks
110 VAC
24 VDC
0 A
No-load stability
110 VAC
24 VDC
3 A
≥ 88
220 VAC
24 VDC
0 A
No-load stability
220 VAC
24 VDC
3 A
≥ 90
Technical specifications - standards complied with
Designation
Standard
Values
Electrical safety
EN 60950 / UL 60950 / CAN/CSA 22.2 950, 3 Edition
Conducted interference EN 61000-6-3
EN 55011
Class B
Emission EN 61000-6-3
EN 55011
Class B
All values are measured at full-load and at an ambient temperature of +25 ℃ (unless
specified otherwise).
