STONEX R2 User Manual

STONEX R2
102
OPERATIONAL STEPS
OPERATION
DISPLAY
①In COGO Main Menu, press [F2],
then in Intersection menu, press [F1],
to enter into Bearing-Bearing
Intersection function.
[F2]
[F1]
【COGO Main Menu】
F1 Inverse & Traverse
F2 Intersections
F3 Offset
F4 Extention
【Intersections】
F1 Bearing-Bearing
F2 Bearing-Distance
F3 Distance- Distance
F4 By Points
②Input PtID of known point P1, and
press [ENT] to move to the next item.
Input PtID1
+
[ENT]
【Bearing-Bearing】
Input data!
Point 1： 10
AZ : --- °---′---″
Point 2： ---
AZ： ---°---′---″
MEAS CALC SEARCH ↓
LIST ENH ∣←
③Input the azimuth from P1 to P3 and
press [ENT] to move to next item.
Input AZ1
+
[ENT]
【Bearing-Bearing】
Input data!
Point 1： 10
AZ : 45°00′00″
Point 2： ﹉
AZ： ---°---′---″
MEAS CALC SEARCH ↓
LIST ENH ∣←
④Input PtID of another known point
P2, and press [ENT] to move to the
next item. Repeat step ②.
Input PtID2
+
[ENT]
【Bearing-Bearing】
Input data!
Point 1： 10
AZ : 45°00′00″
Point 2： 11
AZ： ---°---′---″
MEAS CALC SEARCH ↓
LIST ENH ∣←
