②Press [F1] (list) into the disk list. ‴
1)
Disk: A local disk
Disk: B insert the SD card (if the
disk partition has enough space, it will
show C / D ... disk, does not support
Chinese file name and the Chinese
directory)
Press [F4] (OK) to enter the disk
where the job to be called. )
[F1]
+
[F4]
View job
Disk:A
Disk:B
Attr. Format OK
③Press navigation key( ) to view all
the jobs in internal memory. When
selecting the needed job, press [F4]
(ENT) to set it as the current job, and
then back to the job setting interface.
+
[F4]
View Job
PLAN.RAW 80B 10-00
STON.RAW 90B 10-08
DDDO.RAW 93B 10-09
Attr. PrevPG NextPG
④ Screen displays "Job set ready!"
Return to Setting Meas. The project
will be set in front of "*" logo The
screen displays “Job set already!” and
returns to Setting Meas menu. In front
of the item finished setting, there will
be a"*".
【Setting Meas】
[*] F1 Setting Job (1)
[ ] F2 Setting Station (2)
[ ] F3 Set Orientation (3)
F4 Start (4)
Note: It is forbidden to disconnect the SD card during the process of files in it, otherwise，it may lead
to data loss or damage.
All subsequent recorded data is stored in the current job.
If no job was defined and an application was started or if in “Measure” [All] or [REC]
was triggered, then the system automatically creates a new job and names it “DEFAULT”.
5.2 SETTING STATION
Each coordinate computation relates to the currently set station.
At least plan coordinates (E, N) are required for the station. If necessary, the station height
can be entered. The coordinates can be entered either manually or read from the internal
memory.
