③Then the screen displays the known
point information in the present job.
【View Known Pt】
Job ： A:\2222.PTS
Pt ID： 1
X/N ： 100.000 m
Y/E ： 100.000 m
H/Z ： 90.000 m
SEARCH DELETE ADD EDIT
④press to view all the known
points in this job one by one. ‴1)
【View Known Pt】
Job ： A:\2222.PTS
Pt ID： 2
X/N ： 100.000 m
Y/E ： 200.000 m
H/Z ： 80.000 m
SEARCH DELETE ADD EDIT
6.2.1 Searching Known Points
Input pointIDs or wildcard “*” to search for known points in selected job.
OPERATIONAL STEPS
OPERATION
DISPLAY
①select a job (or all jobs). Press [F1]
(SEARCH) to start Search function.
【View Known Pt 】
Job ：A:\2222.PTS
Pt ID： 1
X/N ： 100.000 m
Y/E ： 100.000 m
H/Z ： 90.000 m
SEARCH DELETE ADD EDIT
②A dialog appears as the right graph.
Input PtID or wildcard “*” and press
[ENT].
SEARCH
Job ：A:\2222.PTS
Pt ID： *
BACK .
③Displays searching result dialog.
If a certain known point is to be
searched, the coordinate information of
this point appears.
If wildcard “*” is input, press
to display all the known points in the
job one by one.
View Known Pt
Job：A:\2222.PTS
Pt ID： 1
X/N ： 0.000 m
Y/E ： 0.000 m
H/Z ： 0.000 m
SEARCH DELETE ADD EDIT
6.2.2 Adding Known Point
Popup a dialog to input PtID and coordinate of a new known point.
