STONEX R2
1) Focus (Actively measured field)
2) Icons
3) Fixed keys (Keys with firmly assigned functions)
4）Alphanumeric keys
5) Navigation keys (Control of input bar in edit and input mode or control of focus bar.)
6) Soft keys (Are assigned the variable functions displayed at the bottom of the screen.)
7) Soft bar (Displays functions that can be called up with the Soft keys. It can use to start
up figure and character input function in R Series.)
8) Trigger key (important key)
9) Power key
1.4 FIXED KEYS
[User]: User key can be defined. Programmable with function from the “Function” menu.
[FNC]: Measurement key in common use. Several functions could be called up, the
instructions are as follows：
²function could be started up directly in different application.
²every function in menu could be appointed to user key (see“4.4 MAIN SETTINGS”)
[Menu]: Menu key. Accesses to programs, settings, data manager, communication
parameters, instrument adjustments, system information and data transfer, etc.
In menus with multiple entries a shortcut number is shown on the right of each entry.
Using this number allows a direct start without turning page.
[PAGE]: Page key. Turn to next page when a dialogue consists of several pages.
[ESC]: Quit a dialog or the edit mode with activation of the “previous” value. Return to a
higher level.
[ENT]: Confirm an input, continue to the next field.
1.5 TRIGGER KEY
The measurement trigger (important key) has three settings (ALL, DIST, OFF). The key
can be activated in Settings or Main Settings menu.
1.6 SOFT KEYS
（
FUNCTIONAL KEYS
）
The measurement data is displayed in the
several upper lines of the display, while a
selection of commands and
functions is at the bottom of the screen,
which can be activated with
corresponding functional keys. The
【Measure】 1/4
PtID ： A1
R.HT： 1.500m
HR： 0°00′00″
V： 90°00′00″
： ---.--- m Ⅰ
： ---.--- m
ALL DIST RECORD ↓
To Next Page
