STONEX R2
81
5.6.1.2 Inputting Coordinate Manually
Press [ENH], [MANUAL] to input stake-out point manually.
Approach 1: Press [ENH] to input the coordinate of stake-out point to the job.
OPERATIONAL STEPS
OPERATION
DISPLAY
①Press [F4] (↓) to turn to Page 2.
[F4]
【Stake Out 】 1/3 ▼
FIND : *
PtID： 5
Type： Known
△Hz ： -85°51′31″
△ ： 2.055 m Ⅰ
△ ： ---.--- m
All DIST RECORD ↓
VIEW EDM ENH ↓
② Press [F3] (ENH) to input PtID and
ENH of the stake-out point. After one
setting, press [ENT] to move to next
item.
[F3]
Input PtID &
ENH
+
[ENT]
【Coordinate Input】
Job ： STONEX
PtID： ﹉﹉
X/N ： --- ---.--- --- m
Y/E ： --- ---.--- --- m
H/Z ： --- ---.--- --- m
BACK SAVE
③ After finishing input, press [F4] to
save the data, and enter into stake-out
program. Start staking out the input
points. ‴1)
[F4]
【Stake Out 】 1/3 ▼
FIND : 5
PtID： 5
Type： Known
△Hz ： -85°51′31″
△ ： 2.055 m Ⅰ
△ ： ---.--- m
VIEW EDM ENH ↓
‴1) Method to stake out is introduced in 5.6.2.
