79
5.5.2 Coding
Three Coding Methods are available:
1. Simple Coding:
Input a code into the relevant box. The code is stored along with the corresponding
measurement.
2. Expand Coding:
Press [CODE]. The input code is searched within the code list and it is possible to add
attributes to the code.
3. Quick Coding:
Press [Q-Code] and enter the abbr. of the code. The code is selected and the measurement
starts.
For more information, please refer to “3.3.4 Coding”.
5.6 STAKING OUT
This program calculates the required elements to stake out point coordinates or manually
entered angles, horizontal distances and heights. Stake-out differences can be displayed
continuously.
Stake Out Steps:
1. Setting job
2. Setting station
3. Setting orientation
4. Calling up coordinates from internal memory. These coordinates may be measured, or
input manually.
5. Staking out. Three methods of stake-out are available: Polar Stake Out, Orthogonal
Stake Out, and Coordinate Offset Stake Out.
5.6.1 Setting Stake-Out Point
5.6.1.1 Calling up Coordinates from job.
OPERATIONAL STEPS
OPERATION
DISPLAY
① After setting job, station and
orientation azimuth, press [F4] in
Setting Meas menu to start stake-out.
‴1)
[F4]
【Setting Meas】
[*] F1 Setting Job (1)
[*] F2 Setting Station (2)
[*] F3 Set Orientation (3)
F4 Start (4)
