STONEX R2 User Manual

STONEX R2
135
OPERATIONAL STEPS
OPERATION
DISPLAY
①Use soft keypad below the screen,
press [PREV] or [NEXT] to find out
the alignment data needed to edit.
User may also press [SEARCH] to
search for the data needed to edit. In
“Find VT Alignment” dialog, input the
chainage of alignment data needed to
edit, and press [ENT].
[F1]
or[F2]
[F3]
+
Input chain
[SEARCH]：
【Define VT AL】 16/16
Chain. ： 100.000 m
H/Z ： 100.000 m
Length： 0.000 m
PREV NEXT SEARCH ↓
START LAST DELETE ∣←
【Search VT Alignment】
Chain. ： ---.--- m
OK
②Input new data, and press [ENH].
Input new
data
+
[ENT]
【Define VT AL】 2/2
Chain. ： 150.000 m
H/Z ： 25.010 m
Length: 20.000 m
PREV NEXT SEARCH ↓
③Press [F2] (NEXT), the procedure
displays “Save Edit Alignment?”. If
yes, press [F4] (OK); To re-edit it,
press [F1] (CANCEL).
[F2]
【Define VT AL】
Save Edit Alignment?
CANCEL OK
④Screen displays next data.
【Define VT AL】 2/2
Chain. ： 280.000 m
H/Z： 15.010 m
Length： 10.000 m
PREV NEXT SEARCH ↓
5.12.6 Deleting Vertical Alignment Data
The vertical alignment data in internal memory can be deleted. Operation is shown below.
