△ ： Height correction
△ ： Correction of the horizontal distance
△Hz ： Correction of HZ angle.
SIGNIFICANT INFORMATION
If the orientation is only measured in telescope Face II, the HZ orientation is based on
telescope Face II. If measured only in telescope Face I or mixed the HZ orientation is
based on Face I.
The prism height may not be changed during measurements in the first and second
telescope position.
If a target point is measured several times in the same telescope position, the last valid
measurement is used for the computation.
If no orientation was set and an application was started, and if in “Measure” [All] or
[REC] was triggered, then the current HZ direction and V-angle are set as orientation.
5.4 APPLICATIONS
Introduction
Applications are predefined programs that cover a wide spectrum of surveying duties and
facilities daily work in the field.
Applications listed as follow are available.
²Surveying
²Stake Out
²Free Station
²COGO
²Tie Distance
²Area (Plan)
²Remote Height
²Reference Line/Arc
²Roads
²Construction
STEPS:
Press fixed key [MENU].
Press [F1]-[F4] to select “Program” option.
Orientation Residuals
BsPt： BS1
△Hz ： 0°00′02″
△ ： -0.005 m
△ ： 0.003 m
BACK
