STONEX R2 User Manual

STONEX R2
43
④Procedure starts code searching to
search the quick coding in internal
memory.
If find the quick coding corresponding
to the code, then the survey function
will start, and the survey result and
quick coding will be displayed as this
survey is finished.
If the quick coding corresponding to
the code doesn‟t exist in internal
memory or the code quantity in
internal memory is smaller than the
code, it will display “Code no Exist!”
‴2)
【Measure】 3/4
Pt ID： A1
Code： CODING
RHT： 1.500 m
HZ： 63°40′50″
V:： 94°33′51″ Ⅰ
： 1.963 m
All Q-CODE EDM ∣←
‴1)Even if only 1digit is dispatched to the coding in “code block manager”, 2 digit numeric code should
be inputted. E.g.: 4->Input 04
‴2)If the code is input on the instrument, or the code has not been dispatched a quick code in “code block
manager”, the code will be numbered in its save sequence, therefore, as the input quick code is bigger than
the total number of codes, the program will prompt “Code no Exist!”
4. FUNCTIONS
Several functions can be called up via [FNC] key.
Functions can also be started directly from different applications.
Each function from the FNC menu can be assigned to the [USER] key. (See 4.4
“Main Settings”)
Several functions：
Light ON/OFF
Switches display light on/off.
Units
Display the current distance and angle unit. Pressing or can change the units.
After one setting is finished, move to the next by pressing or . When all settings are
done, press [SET] to save and return.
Free-Coding
Select codes from the code list or enter a new code.
