14．SPECIFICATION
Distance measurement (visible laser)
a), Type„„„„„„„„„„ visible red laser
b), carrier wave„„„„„„„ 0.670μ m
c), measuring system„„„„„ basis 60 MHZ
d), EDM Type „„„„„„„ coaxial
e), Display (least count) „„„ 1mm
f,) laser dot size „„„„„„ approx.7³14 ㎜ / 20m (reflectorless mode only)
approx. 10³20 ㎜ / 50m
g), Accuracy
With reflector:
EDM measuring
program
Accuracy Standard
deviation
Time per
measurement
fine
2 ㎜＋2ppm
＜1.8s
fast
3 ㎜＋2ppm
＜1.2s
tracking
5 ㎜＋2ppm
＜0.8s
IR-tape
5 ㎜＋2ppm
＜1.2s
Without reflector:
EDM measuring
program
Accuracy Standard
deviation
Time per
measurement
Reflectorless fine
5＋2ppm
＜1.2s
Reflectorless
tracking
10＋2ppm
＜0.8s
h), range
With reflector
Atmospheric conditions
Standard prism
Reflector tape
5km
1000m
300m
20km
4000m
800m
Without reflector
Atmospheric conditions
No reflector（white
No reflector
