2.7.1 Inputting Character
For STONEX R2: each key is defined with three characters and a figure, as entering the
number/letter inputting mode, every time you press the keypad, a letter would occur at the
cursor, and a number occurs by pressing four times. As the needed character/fig occurs,
the cursor moves automatically to the next item.
E.g.: input 123ABF8
OPERATIONAL STEPS
OPERATION
DISPLAY
①Press the key on numeric keypad to
start inputting. As the sign at the
lower-right corner of the screen is [01],
it is in the numeric inputting mode.
【Measure】 1/4
Pt ID ： 1
RHT ： 1.500 m
HZ ： 0°00′00″
V ： 90°00′00″
： ---.--- m Ⅰ
： ---.--- m 01
INSERT DELETE CLEAR NUMBER
② Press numeric key 123, after
inputting figures, press [F4] (ALPH) to
enter character inputting mode.
Input [1]
[2]
[3]
+
[F4]
【Measure】 1/4
Pt ID ： 123
RHT ： 1.500 m
HZ ： 0°00′00″
V： 90°00′00″
： ---.--- m Ⅰ
： ---.--- m AB
INSERT DELETE CLEAR NUMBER
③ Press numeric key “7” once,
showing letter A, the cursor
automatically moves to the next
position, press “7” twice, showing B,
then press “8” three times, showing F,
finally, press “8” four times, to show 8.
So as to finish inputting 123ABF8.
Input [A]
[B]
[F]
[8]
【Measure 】 1/4
Pt ID ： 123ABF8
RHT ： 1.500 m
HZ ： 0°00′00″
V： 90°00′00″
： ---.--- m Ⅰ
： ---.--- m AB
INSERT DELETE CLEAR NUMBER
④Press [ENT] to end inputting and
move to the next item.
[ENT]
【Measure】 1/4
Pt ID ： 123ABF8
RHT ： 1.500 m
HZ： 0°00′00″
V： 90°00′00″
： ---.--- m Ⅰ
： ---.--- m
ALL DIST RECORD ↓
