STONEX R2 User Manual

STONEX R2
31
HD =
Grid
HDg
Note: 1.Inputting range of scale:0.990000 ～ 1.010000. The default value: 1.00000
2.Inputting range of average altitude:-9999.8 ～ 9999.8
The average altitude value is rounded off to the nearest tenth and the default value is
zero
OPERATIONAL STEPS
OPERATION
DISPLAY
①On the screen of EDM setting , press
[F2](GRID) to enter Grid Factor
setting.
[F2]
【EDM Settings】
EDM Mode： Tracking
Reflect: Prism
Prism： 30.0mm
ATMOS GRID SET ↓
②The current settings display on the
screen, input Scale and Ht.a.MSL and
press [ENT]. The procedure will
calculate and display grid. To set All
settings to 0 value, press [F3] (0SET).
‴1)
Input Scale
+
[ENT]
Input
Ht.a.MSL
+
[ENT]
【Grid Factor】
Scale ： 1.000000
Ht.a.MSL： 0.0 m
Grid： 1.000000
BACK 0SET SET
③Press [F4](SET) to save the settings
and return to the previous menu, then
press [F3](SET) again to save the
settings being done, and return to
measure function.
[F4]
[F3]
【EDM Settings】
EDM Mode： Tracking
Prism： 30.0mm
ATMOS GRID SET ↓
‴1) Please refer to “2.7 inputting mode” for inputting instruction.
3.2.6 Viewing Signal of Distance Measurement
This function displays the intensity of returned-ray signal (signal intensity) being received
by the total station instrument, step length 1%. Once refraction ray from the prism is
received, this instrument will make beep sound and show the ray intensity which is
expressed by %. The best collimation precision can be realized by this function when the
target is difficult to find or see.
