STONEX R2
64
5.2.1 Calling up a Job from Internal Memory-[SEARCH]
STEPS: 1. Select a PtID stored in internal memory.
2. Input instrument height.
[OK] Sets the station.
OPERATIONAL STEPS
OERATION
DISPLAY
①Press [F2] in Setting Meas menu to
enter into Setting Station menu.
[F2]
【Setting Meas】
[*] F1 Setting Job (1)
[ ] F2 Setting Station (2)
[ ] F3 Set Orientation (3)
F4 Start (4)
② Enter the PtID of known point and
press [ENT].‴1)
Input PtID
+
[ENT]
【Setting Station】
Input Station Pt. ID!
Stn Pt:
SEARCH LIST ENH
③Press[F1](SEARCH)：
A：If the PtID exists in the job, the
screen will display as the right picture.
If there are several points, the program
will list them separately.
B：If the input PtID does not exist, the
program will imply “PtID No Exist!”,
and then display Coordinate Input
menu.
A：
B：
【Pt Search】 4
12 Known
12 Meas.
12 Meas.
12 Meas.
SEARCH ENH JOB OK
