②Input point name of the known P1
point, and press [ENT] to move cursor
to the next line. ‴1)
Input PtID1
+
[ENT]
【Point- Offset】
Define Baseline!
Point 1： 20
Point 2： --- --- ---
Toff & Loff!
Line： --- --- ---
Offset : --- --- ---
MEAS CALC SEARCH ↓
LIST ENH ∣←
③ Input another PtID of the known
point P2, and press [ENT].
Input PtID2
+
[ENT]
【Point- Offset】
Define Baseline!
Point 1： 20
Point 2： --- --- ---
Toff & Loff!
Line： --- --- ---
Offset : --- --- ---
MEAS CALC SEARCH ↓
④Input Toff & Loff, and press [ENT].
Input Toff &
Loff
+
[ENT]
【Point- Offset】
Define Baseline!
Point 1： 20
Point 2： 22
Toff & Loff!
Line： 12.000 m
Offset : 20.200 m
MEAS CALC SEARCH ↓
⑤Press [F2] (CALC) to display the
result.
To stake out this point, input new PtID,
and press [F1] to start staking out.
‴2)
To save the data, press [F4].
To quit the result menu, press [ESC] to
return to data inputting menu, and
re-input the data.
【COGO New Point】
New Point : --- --- ---
X/N ： 22.627 m
Y/E ： -5.657 m
STAKE RECORD
‴1) There are four methods to input the known PtID. Please refer to step ② of the last section
“5.8.1.1Traverse”.
‴2) The stake-out operation is similar to that of Traverse, which has been introduced previously. Please
refer to “5.8.1.1 Traverse”.
5.8.4 Extension
“Extension” is used to compute extension points from the baseline.
