76
Calling up applications and activating start programs. Press [PAGE] to turn to next page.
5.5 SURVEYING
The measurement of an unlimited number of points is supported in surveying program. It
is comparable to “Measure”, excluding stationing, orientation and coding.
OPERATION: Set job, station and orientation first!!
OPERATIONAL STEPS
OPERATION
DISPLAY
① After setting job, station and
orientation, press [F4] in Setting Meas
menu to start measurement.
[F4]
Setting Meas
[*]F1 Setting Job (1)
[*] F2 Setting Station (2)
[*] F3 Set Orientation (3)
F4 Start (4)
② Input PtID and press [ENT] to
move to next item. ‴1)
Input PtID
+
[ENT]
【Measure】 1/3
PtID： 1
R. HT： 1.860 m
Code: ------
HZ： 0°00′00″
V ： 90°00′00″ Ⅰ
： ---.--- m
All DIST RECORD ↓
