STONEX R2 User Manual

STONEX R2
44
4.1 LEVELING
As the tilt sensor is activated, automatic correction of vertical angle for unlevelment is
displayed.
To ensure a precise angle measurement, tilt sensor must be activated (See 4.4 Main
Settings), and the display can be used to fine level the instrument.
If the instrument hasn‟t been leveled roughly, the screen displays that the instrument is out
of the automatic correction range, and that it needs to be leveled manually. Please refer to
“2.2 Instrument Setup” for detailed leveling instruction.
STONEX R2 Total Station compensates the vertical angle reading due to inclination
of the vertical axis in the X directions.
OPERATION STEPS
OPERATION STEPS
OPERATION
DISPLAY
①Press FUNCto enter into the routine
function Menu, then press F1 (Level),
then enter the Tilt adjust screen. Then
press PAGE to find the value, if the
value is within ±3′, it indicates that it
is with the designed range of automatic
tilt correction. Press [F4] to return to
Measure menu.
If the value exceeds ±3′ , manual
leveling is a must.
[F1]
【Tilt Adjust】
F1 Level
F2 Target Offset
F3 Delete Last Record
F4 Main setting
F1 F2 F3 F4
【Tilt Adjust】
X：-0°10′21″
Y：-0°07′08″
BACK
②If the instrument hasn‟t been leveled
precisely, rotate the tribrach screws
and level the instrument according to
the value‟s changing displayed in the
screen.
【Tilt Adjust】
X：-0°00′21″
Y：-0°00′08″
BACK
③After leveling, press [F4] to return
to Measure menu.
When the instrument is placed on an unstable stage or in a windy weather condition,
