① Individual code blocks can be
entered directly via keypad. Once an
item is finished, press ENT to move
the cursor to the next attribute. ‴1)
Input the
coding
attributes
+
[ENT]
【Code Search】 1/2▼
Select / Input new code！
Search：
Code： --- ---
Desc ： --- ---
Info1 ： --- ---
Info2 ： --- ---
RECORD ADD OK
②A：Press [F1](RECORD) to return
to Measure function, and set the
input coding as the code of the
present measuring point, add a new
coding datum to Measurements
document ‴2)
B: Press [F2] (ADD). Besides
returning to measure function and
setting the input code as the code of
present measuring point, a new code
will also be added to the code
storeroom. ‴3)
C: Press [F4] (OK) only to set the
input code as the code of present
measuring pointID and return to
measure function. Only by starting
surveying can the input coding be
saved into Measurements documents
along with measuring operations.
‴4)
A ： The code data being added to
Measurements document
B：New code added in the code storeroom:
C：
【VIEW】 88
Mode： CODING SYS.MESS
Pt ID： --- --- ---
Code： STONEX
Desc： --- --- ---
Date： 05.08.2006
Time： 11:29:41
SEARCH
【Code search / delete】1/2 ▼
Search： *
Code ： STONEX
Desc： VIP
Info1 ： --- ---
Info2 ： --- ---
Info3 ： --- ---
NEW DELETE
【Measure】 3/4
Pt ID： A1
CODE： STONEX
RHT： 1.500 m
HZ： 63°40′50″
HZ： 94°33′51″ Ⅰ
： ---.--- m
All CODE EDM ↓
‴1)Press [PAGE] to edit /view the other pages of the coding attributes
‴2)The added coding datum can be seen in Measurements of File Management.
‴3)The added coding can be found in the code storeroom.
‴4)Press [OK] to conclude the coding function, the coding blocks are kept in the system temporarily,
and they can only be recorded together with the practical measurement point.
The settings of coding record in “Settings” or “Main settings” are: save before and save after,
here explain separately as follows：
save before：to save coding data before practical survey data
save after ：to save the coding data closely after practical survey data
Please inquire in “Measurements” document.
