STONEX R2 User Manual

STONEX R2
101
④ Press [F2](CALC) to display the
result.
[F2]
【Inverse Result】
Point 1： 21
Point 2： 22
AZ ： 90°00′00″
△ ： 10.000 m
△ ： 10.000 m
△ ： 0.000 m
RECORD
⑤ To record the result, press [F4].
To quit the result menu, press [ESC] to
proceed to the next Inverse function.
【Inverse】
From ：
To：
MEAS CALC SEARCH ↓
‴1) There are four approaches to obtain the known PtID. Please refer to Step② of the last section
“5.8.1.1Traverse”.
5.8.2 Intersections
5.8.2.1 Bearing-Bearing
The known data:
P1 The first known point
P2 The second known point
α 1 Direction from P1 to P3
α 2 Direction from P2 to P3
The unknown data: P3 COGO point
