STONEX R2 User Manual

STONEX R2
147
③After the start point of site has been
decided, input prism height, collimate
the prism center, press [F2](DIST)+
[F3] (RECORD) to start measurement.
[F2]
+
[F3]
【Define new Site】
Sight Meas Start Pt!
StartPt： 1
R.HT： 2.000 m
： ---.--- m Ⅰ
： ---.--- m
All DIST RECORD ↓
EDM ENH |←
④ Following Step ② to determine
the end point of site, and input the
prism height, and press [F2] (DIST) +
[F3] (RECORD) to start measurement.
[F2]
+
[F3]
【Define new Site】
Sight Meas Start Pt!
StartPt: 1
EndPt: 2
R.HP： 2.000 m
： ---.--- m Ⅰ
： ---.--- m
All DIST RECORD ↓
⑤To display the result screen.
[F1]：Reject the result, and rebuild the
site.
[F4]：Accept the result to set the line
and enter into stake out screen.
【Construction Check】
Known Length： 12.635 m
Meas. Length： 12.640 m
Offset： -0.005 m
REFUSE OK
5.13.2 Shifting Line
[ShiftL]: Input horizontal shifting value to horizontally shift the line.
The line can be horizontally shifted according to the requirement of job.
OPERATIONAL STEPS:
OPERATIONAL STEPS
OPERATION
DISPLAY
① To horizontally shift the line, press
[F4] (↓), and press [F3] (ShiftL).
[F4]
[F3]
【AS-BuiltCheck】
PtID： 3
R.H： 1.500 m
Ln： ---.--- m
Of： ---.--- m
H： ---.--- m
All DIST STAKE ↓
DIST RECORD ShiftL |←
