STONEX R2 User Manual

STONEX R2
47
When the “Permanent” is selected, the
program will always display the data
added the offset correction.
【Measure】
PtID： A2
R.HT： 1.500 m
HZ： 0°00′00″
V： 90°10′50″
： 2.568 m Ⅰ
： 1.689 m
All DIST RECORD ↓
⑦ If there is no more point of target
offset to measure, repeat step ① to
restart the Target Offset function.
【Target Offset】
Input Offset!
T_Offset : 0.000m
L_Offset : 0.000m
H_Offset : 0.000m
MODE： Set After REC
0SET OK
‴1) If the coordinate of target point is needed to calculate, please set the coordinate of station, heights of
instrument and reflector, backsight point, etc.
The period of applicability can be set as follows:
MODE
EXPLANATION
0set After REC
The offset values are set to 0 after the point is saved.
Permanent
The offset values are applied to all further measurements.
The offset values are always reset to 0 when the application is quit.
4.3 DELETING LAST RECORD
This function deletes the last recorded data block, which can be either a measurement
block or a code block.
Deleting the last record is irreversible!
Only records recorded during measurement can be deleted.
OPERATION STEPS:
OPERATIONAL STEPS
OPERATION
DISPLAY
① Press [FNC] to enter into the
Function menu.
FNC
【Function】1/4 ▼
F1 Level (1)
F2 Target Offset (2)
F3 Delete Last Record (3)
F4 Main Settings (4)
