②Press [F2] to enter into Target Offset
function.
Input the offset values (length, cross
and/ or height offset values).Define the
period for which the offset is to apply.
Press [F1] (OSET) to set eccentricity
to zero.
Press [F4] to confirm.
[F2]
+
Input
offset values,
period of
applicability
+[ENT]
+[F4]
【Target Offset】
Input Offset!
T_Offset : 0.000m
L_Offset : 0.000m
H_Offset : 0.000m
MODE： 0set After REC
0SET OK
③ Press navigation key to
select the period of applicability. The
modes available are: 0Set After REC
and Permanent.
After finishing all the settings, press
[F4] to save.
+
[F4]
【Target Offset】
Input Offset!
T_Offset : 0.000m
L_Offset : 0.000m
H_Offset : 0.000m
MODE： 0set After REC
0SET OK
④ The program calculates the
corrected values and returns to the
application from which the offset
function was started.
Collimate the center of reflector and
press [F2] to start measuring. ‴1)
[F2]
【Measure】 1/4
PtID： A2
R.HT： 1.500 m
HZ： 0°00′00″
V： 90°10′50″
： ---.--- m Ⅰ
： ---.--- m
All DIST RECORD ↓
⑤The corrected angle and distances
are displayed when a valid distance
measurement has been triggered or
exists.
【Measure】
PtID： A2
R.HT： 1.500 m
HZ： 0°00′00″
V ： 90°10′50″
： 5.568 m Ⅰ
： 3.689 m
All DIST RECORD ↓
⑥When “0set After REC” is selected:
If [All] is started, the program will
display the data (the target point)
which is calculated by adding the
measured result and the offset
correction.
If [DIST] is started, you must restart
measurement after pressing
[RECORD] to display the actual value
of the measurement point.
Displays the Rec. data beforehand.
Restart measurement, displaying the data of
measurement point：
【Measure】
PtID: A2
R.HT： 1.500 m
HZ： 0°00′00″
V： 90°10′50″
： 5.568 m Ⅰ
： 3.689 m
All DIST RECORD ↓
