STONEX R2 User Manual

STONEX R2
106
②Input PtID of known point P1, and
press [ENT] to move to next item.
‴1)
Input PtID1
+
[ENT]
Distance-Distance
Input data!
Point 1： 10
H-Dist： ---.--- m
Point 2： ---
H-Dist： ---.--- m
MEAS CALC SEARCH ↓
LIST ENH ∣←
③ Input horizontal distance between
P1 and P3 or P4 (r1).
Input HD1
+
[ENT]
【Distance-Distance】
Input data!
Point 1： 10
H-Dist： 50.000 m
Point 2： ---
H-Dist： ---.--- m
MEAS CALC SEARCH ↓
LIST ENH |←
④Input the known point P2. Repeat
step ②.
Input PtID2
+
[ENT]
【Distance-Distance】
Input data!
Point 1： 10
H-Dist： 50.000 m
Point 2： 11
H-Dist： ---.--- m
MEAS CALC SEARCH ↓
LIST ENH |←
⑤ Input horizontal distance between
P2 and P3 or P4 (r2).
Input HD2
+
[ENT]
【Distance-Distance】
Input data!
Point 1： 10
H-Dist： 50.000 m
Point 2： 11
H-Dist： 20.000 m
MEAS CALC SEARCH ↓
LIST ENH ∣←
⑥Press [CALC] to display the result.
To stake out this point, input new PtID,
and press [F1] to start staking out.‴2)
To save the data, press [F4].
To quit the result menu, press [ESC] to
return to data inputting menu, and
re-input the data.
[F2]
【COGO New Point】
New Point ： --- --- ---
X/N ： 4.000 m
Y/E ： -19.596 m
New Point 2： --- --- ---
X/N ： 4.000 m
Y/E ： 19.596 m
STAKE RECORD
‴1) There are four methods to input the known PtID. Please refer to step ② of the last section
“5.8.1.1Traverse”.
‴2) The stake-out operation is similar to that of Traverse, which has been introduced previously. Please
refer to “5.8.1.1 Traverse”.
5.8.2.4 By Points
